Schneider Electric NQ830L2C Column Width Panelboard

Technical Specification

Features:

Make: Schneider Electric
Model code: NQ830L2C
Type: Main lugs
Application: Industrial
Number of Phases: 1

Additional info:

240 Vac maximum (NQ) or 480Y/277 Vac maximum (NF) 100 - 225 Amp main circuit breaker or main lugs 65kA maximum fully rated branch SCCR (@ 480Y/277 Vac for NF, or @ 240 Vac for NQ) 60 Amp maximum branch circuit breaker Accepts plug-on (NQ) or bolt-on branch circuit breakers (NQ or NF) Solid neutral located on same end as mains Galvanized steel enclosure with removable endwalls Finish: gray-baked enamel electrodeposited over cleaned, phosphatized steel All lugs are suitable for 75° C copper or aluminum wire

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Schneider Electric
Manufacturer	Schneider Electric
Category	Transmission and Distribution>Panelboards
Model code	NQ830L2C
Type	Main lugs
Application	Industrial
Number of Phases	1
Max. Voltage	240 V AC
No. of spaces	30
Max. Current	225 A
Wiring configuration	3-wire
Busbar Material	Copper
Depth	5 in
Height	45 in
Width	8.625 in
Standards	CSA, UL
Additional info	240 Vac maximum (NQ) or 480Y/277 Vac maximum (NF) 100 - 225 Amp main circuit breaker or main lugs 65kA maximum fully rated branch SCCR (@ 480Y/277 Vac for NF, or @ 240 Vac for NQ) 60 Amp maximum branch circuit breaker Accepts plug-on (NQ) or bolt-on branch circuit breakers (NQ or NF) Solid neutral located on same end as mains Galvanized steel enclosure with removable endwalls Finish: gray-baked enamel electrodeposited over cleaned, phosphatized steel All lugs are suitable for 75° C copper or aluminum wire
