Eaton SCB10-1600/10 Dry-type Transformer

Technical Specification

Features:
  • Make: Eaton
  • Model code: SCB10-1600/10
  • Type: Resin-insulated dry-type transformer
  • Unit ratings or power ratings: 1600 kVA
  • Frequency range: 50/60 Hz
Read more
Additional info:

Non-Flammable - The insulating materials will not self-ignite and are selfextinguishing. Efficient & Quiet - Transformer have low losses and low sound level. Environmentally Safe - Units are non-polluting and require little maintenance. Dielectric Integrity - Transformer are free of partial discharge and withstand high Basic Impulse Levels. High Short-Circuit Strength - Units are resistant to short-circuit forces. Hermetically Sealed - Transformer are impervious to humidity and most common industrial contaminants. Low Installation Cost - Transformer can be installed close to the load center without costly vaults, dikes and special ventilation. Conserve Valuable Space - Designs are compact and light weight

Read more
Make Eaton
Manufacturer Eaton
Category Transmission and Distribution>Transformers
Model code SCB10-1600/10
Type Resin-insulated dry-type transformer
Unit ratings or power ratings 1600 kVA
Frequency range 50/60 Hz
No. of Phases Three-phase
Standards/Approvals GB1094, IEC60076
Winding material Copper
Protection IP00, IP20, IP23
Insulation class/temperature Class: F or H
Additional info
  • Non-Flammable - The insulating materials will not self-ignite and are selfextinguishing.
  • Efficient & Quiet - Transformer have low losses and low sound level.
  • Environmentally Safe - Units are non-polluting and require little maintenance.
  • Dielectric Integrity - Transformer are free of partial discharge and withstand high Basic Impulse Levels.
  • High Short-Circuit Strength - Units are resistant to short-circuit forces.
  • Hermetically Sealed - Transformer are impervious to humidity and most common industrial contaminants.
  • Low Installation Cost - Transformer can be installed close to the load center without costly vaults, dikes and special ventilation.
  • Conserve Valuable Space - Designs are compact and light weight
