Allied Tube & Conduit IMC - 1 1/2 Light-weight Ductile Steel Conduit

Technical Specification

Features:

Make: Allied Tube & Conduit
Model code: IMC - 1 1/2
Trade Size: 1 1/2 inch
Material: Ductile steel
Outside Diameter: 1.883 inch

Additional info:

Light-weight ductile steel conduit for long life and easy bending Weighs 1/3 less than rigid conduit Saves up to 30% in cost over GRC Hot galvanized exterior to increase corrosion resistance and protect against white rust Interior coating creates a smooth, continuous raceway for fast wire-pulling UL 1242 listed and manufactured in accordance with ANSI C80.6 True Color IMC special orders available

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	Allied Tube & Conduit
Manufacturer	Allied Tube & Conduit
Category	Wires, Cables, Conduits and Overcurrent Protection>Intermediate metallic tubing (IMC)
Model code	IMC - 1 1/2
Trade Size	1 1/2 inch
Material	Ductile steel
Outside Diameter	1.883 inch
Wall Thickness	0.090 inch
Standards	Article 342 of the National Electric Code (NEC), Underwriters Laboratories Safety Standard UL 1242, ANSI C80.6
Weight	88.0 Kg
Additional info	Light-weight ductile steel conduit for long life and easy bending Weighs 1/3 less than rigid conduit Saves up to 30% in cost over GRC Hot galvanized exterior to increase corrosion resistance and protect against white rust Interior coating creates a smooth, continuous raceway for fast wire-pulling UL 1242 listed and manufactured in accordance with ANSI C80.6 True Color IMC special orders available
