ABB PM1212C PowerMark™ PRO Loadcenter

Technical Specification

Features:

Make: ABB
Model code: PM1212C
Series: PowerMark™ PRO
Type: Main Breaker
Application: Residential

Additional info:

Standard main breaker range from 100A to 225A. Main breaker amperages of 40A to 90A can be achieved using accessory MCB mounting kit on 125A PLM versions Available in 8-60 circuit capacity 22k AIC main breaker, series rated 22kA/10kA Single-phase, three-wire, 120/240VAC 60/75°C conductor rating

Contact manufacturer Contact manufacturer Datasheet Datasheet

Make	ABB
Manufacturer	ABB
Category	Transmission and Distribution>Loadcenters
Model code	PM1212C
Series	PowerMark™ PRO
Type	Main Breaker
Application	Residential
Number of Phases	Single
No. of spaces	12
Max. Current	125 A
Wiring configuration	Three
Busbar Material	Copper
Enclosure type	NEMA 1
Standards	UL Listed panelboards No. 67
Additional info	Standard main breaker range from 100A to 225A. Main breaker amperages of 40A to 90A can be achieved using accessory MCB mounting kit on 125A PLM versions Available in 8-60 circuit capacity 22k AIC main breaker, series rated 22kA/10kA Single-phase, three-wire, 120/240VAC 60/75°C conductor rating
